A universal system for the removal and installation of Suspension Bushes, Bearings, Seals etc
By selecting the appropriate diameter sleeves, the bush / bearing / seal is ˜Pressed, or ˜Pulled by the action of turning the spindle nuts in opposing directions.
Fully universal applications for Cars, LCVs HGVs etc, with a range of kit options to suit individual requirements.
Press & Pull Sleeve Kits can be used in the following formats:
As a stand alone set of tools
With a standard workshop press
With a Universal Press Frame (187000V2)
With a Universal C Clamp (18780200)
Can also be used with selected model specific Press Piece sets and in conjunction with optional hydraulic upgrade kits
All components are available individually as spare parts, for full list of spare parts please see spare parts section or instructions in the downloads section.
Universal applications - Car - LCV
Contains 20x Press Sleeves in 2mm diameter steps
Inside Diameter Range: 34 - 72mm
Outside Diameter Range: 44 - 82mm
4x Step Plates / 4x Pulling Spindles with thrust bearings
Supplied in moulded storage case
