53380400 - 120L Oil Extractor with Under-Vehicle Tray

Description

Pneumatic equipment for fast recovery of engine oil from any vehicles. The oil change may take place by gravity, or by aspiration from the engine sump, with hot oil (70/80 ° C) through one of the 6 included probes. Simple to use, the equipment is  provided with a pressure relief valve set at 4 bar. The device is manufactured in compliance with EC rules.

Carbon Steel Reservoir
Epoxy Coated Finish
Pneumatic Extraction
Drain plug for cleaning and internal inspection
Metal drip tray with drain filter grid

Technical Specification
Tray - 51l
Air Inlet Connection - 1/4"
Air Consumption - 200 l/min
Noise level - <80 (dB)
Weight - 83kg
Reservoir Operating Pressure - 4 bar
Capacity - 120l

Dimensions (mm)

A - 660mm
B - 780mm
C - 1520mm
C1 - 2140mm
D - 590mm
E - 220mm
F - 492mm

Product form

Pneumatic equipment for fast recovery of engine oil from any vehicles. The oil change may take place by gravity, or... Read more

SKU: 53380400

Icon for notificationEnquire About This Product

Contact us with an enquiry about this product.

Please include a contact number in the message.

Send us a message!

Description

Pneumatic equipment for fast recovery of engine oil from any vehicles. The oil change may take place by gravity, or by aspiration from the engine sump, with hot oil (70/80 ° C) through one of the 6 included probes. Simple to use, the equipment is  provided with a pressure relief valve set at 4 bar. The device is manufactured in compliance with EC rules.

Carbon Steel Reservoir
Epoxy Coated Finish
Pneumatic Extraction
Drain plug for cleaning and internal inspection
Metal drip tray with drain filter grid

Technical Specification
Tray - 51l
Air Inlet Connection - 1/4"
Air Consumption - 200 l/min
Noise level - <80 (dB)
Weight - 83kg
Reservoir Operating Pressure - 4 bar
Capacity - 120l

Dimensions (mm)

A - 660mm
B - 780mm
C - 1520mm
C1 - 2140mm
D - 590mm
E - 220mm
F - 492mm
