Description
The device gives support to the engine when the side engine bracket is removed, e.g. during maintenance work on thrust bearings, timing belts, water pumps or tensioner rollers
Equipped with two sliding hooks to fit to underbody of vehicles
After loosening the engine mount, the support safely holds the engine in the its compartment, saving time and increasing safety
The device makes it possible to work at the engine control (belt drive) without using engine cranes or transmission lifts, making the engine compartment freely accessible
The supporting base, is adjustable in height and floats up to 8° to line upwith the engine/gear surface. Covered with non-slip rubber
Technical data:
Telescopic arm (to 230 mm)
Load capacity 240 kg
Sliding telescopic arm extension: min. 657/max 887
Side-arms extension: min. 322/max 566.
Arms rotate 360°; the device can be closed completely in order to be stored in small spaces
The two supporting feet are adjustable in height to the vehicle frame, with the support components covered with polyurethane
