Description
SLS - Self-leveling system: the two self-levelling arms allow to work easily on both conical and offset springs.
Cylinder, stroke and thrust: thanks to a stroke of 330 mm it is also possible to use this machine for long shock absorbers of cars and minivans. With an operating pressure of max. 8 bar the machine exerts a compression force of 1226 kg without losing power.
Aluminum technology: the cylinder is made in light alloy and nylon resin with fiberglass avoiding the corrosion and the oxidation of the parts of the machine.
Control valve: the control pedal works only when the machine is connected to the compressed air system. Consequently, the machine can be disconnected without any danger, guaranteeing maximum safety.
Glove compartment: the machine is equipped with a practical and safe glove compartment
Fixed position not removable
Contents:
- 1.2 Ton Spring compressor
- Strut Vice (GO332)
Technical data:
- Dimensions: 1442 x 445 x 576 mm
- Max working pressure: 8 bar
- Compression force: 1.2 Ton
- Cylinder stroke: 330 mm
- Spring compression capacity: 30-300 mm
- Spring exterior: Ø 105-185 mm
- Vacuum Cycle Consumption: 0.07 m³/h 1.17 lt/min
- Load Cycle Consumption: 0.03 m³/h 0.5 lt/min
- CE approved machine in compliance with 2006/42/CE (Machine Directive)
Full range of Govoni available - click to see the Govoni Catalogue or Govoni Garage Equipment Catalogue
